Individual bandsaws

Individual bandsaws

Mössner offers you solutions that fit like a tailor-made suit. We have been in the
sawing business for over 100 years, and you benefit from this experience.

Our sawing systems are established in the most diverse areas, whether graphite, glass, silicon, ceramics, hard metal, magnesium, tyres, foils, metal hoses, etc. We can manufacture your Mössner saw individually adapted to your requirements.

We offer

  • Feasibility studies such as simulations
  • Process-related tests with your materials according to your requirements on our testing machines
  • Development of customised solutions
  • Adaptation of the equipment to your existing system solutions
  • Experience in the field of Industry 4.0
  • Training of your employees

Reference examples

  • Bandsaw SSF 1000 for automatic trimming and cutting of graphite blocks, including angular cuts
  • Component size 720 x 700 x 4200 mm

  • Tyre saw for test cuts on tyres for cars and trucks with clamping device for various tyre dimensions
  • Tyre size 480 – 1000 mm / height up to 450 mm

Video example:

  • Bandsaw SSF 630 for sawing glass, installed on a water basin with a feed table optimized for water and a table enclosure for optimum splash water protection
  • Component size 600 x 400 x 600 mm

  • Bandsaw SSF 801 with a feed table with 2100 travel for sawing ceramics
  • Component size 1000 x 600 x 1800 mm

  • Bandsaw SSF 520 with a feed table and infeed axis, with table enclosure and extraction nozzle for sawing carbide
  • Component size 1000 x 1000 x 300 mm

  • Fully automatic CNC bandsaw SSF 801 for cutting silicon ingots into individual cuboids. Band saw with coolant system and vacuum clamping device
  • Component size 1000 x 1000 x 300 mm

  • Band saw SSF 520 with feed table 350 mm, for sawing magnesium. Machine is equipped with additional safety measures.
  • Component size 500 x 500 x 320 mm

  • Fully automatic horizontal bandsaw with component feed for dividing foil coils into individual sections, with loading and suction robot
  • Coil size ø120 – 600 mm x 3600 mm

Video example:

  • Fully automatic horizontal bandsaw with feeding system for sawing aluminium masts
  • Masts ø100 – 250 mm x 17000 mm

Your contact for individual solutions
